تفاصيل المنتج:
|
| اسم المنتج: | شبكة كابل أسلاك الفولاذ المقاوم للصدأ لشبكة الطيور | مادة: | سلك الفولاذ المقاوم للصدأ 304 |
|---|---|---|---|
| شكل ثقب: | الماس | الاستخدام: | شبكة حماية الطيور |
| مقاس: | تخصيص بناء على الطلب | عينة: | متاح لتوفير العينة |
| فتحة الشبكة: | 20mm*20mm-300mm*300mm | ضمان: | 10 سنوات ضمان |
| إبراز: | 1mm 1.5mm Stainless Steel Rope Wire Mesh,Woven Design Stainless Steel Cable Mesh,Stainless Steel 304 Wire Rope Mesh,Woven Design Stainless Steel Cable Mesh,Stainless Steel 304 Wire Rope Mesh |
||
ROPE MESH (also called cable mesh) made from high quality stainless steel wire rope, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in harsh environments. Its largest benefit is particular resilience and flexibility.
Our rope mesh may be knotted, ferrule type, woven square, or square mesh with cruciate/cross clamps. They are all favored by fashion architects.
| Attribute | Details |
|---|---|
| Material | Stainless Steel 304/316 |
| Product Name | SS Stainless Steel Wire Cable Mesh |
| Hole Shape | Diamond hole shape |
| Usage | Protecting mesh, decorative wire mesh, etc. |
| Length/Width | Customized: 0.1m-8m |
| Sample | Available and free (30*30cm by air) |
| Mesh Aperture | 20mm*20mm-300mm*300mm |
| Warranty | 10 years warranty |
| Thickness | 1mm, 1.2mm, 1.5mm, 1.6mm, 2.0mm, 2.4mm, 3.2mm (customizable) |
| Cable diameter | Mesh opening size | Nominal break |
|---|---|---|
| 1/8 inch (3.2mm) | 4x4 inch (102x102mm) | 1600 lbs. |
| 1/8 inch (3.2mm) | 3x3 inch (76x76mm) | 1600 lbs. |
| 1/8 inch (3.2mm) | 2x2 inch (51x51mm) | 1600 lbs. |
| 3/32 inch (2.4mm) | 4x4 inch (102x102mm) | 920 lbs. |
| 3/32 inch (2.4mm) | 3x3 inch (76x76mm) | 920 lbs. |
| 3/32 inch (2.4mm) | 2x2 inch (51x51mm) | 920 lbs. |
| 5/64 inch (2.0mm) | 3x3 inch (76x76mm) | 676 lbs. |
| 5/64 inch (2.0mm) | 2x2 inch (51x51mm) | 676 lbs. |
| 5/64 inch (2.0mm) | 1-1/2x1-1/2 inch (38x38mm) | 676 lbs. |
| 1/16 inch (1.6mm) | 3x3 inch (76x76mm) | 480 lbs. |
| 1/16 inch (1.6mm) | 2x2 inch (51x51mm) | 480 lbs. |
| 1/16 inch (1.6mm) | 1-1/2x1-1/2 inch (38x38mm) | 480 lbs. |
| 1/16 inch (1.6mm) | 1x1 inch (25.4x25.4mm) | 480 lbs. |
| 3/64 inch (1.2mm) | 1-1/2x1-1/2 inch (38x38mm) | 270 lbs. |
| 3/64 inch (1.2mm) | 1x1 inch (25.4x25.4mm) | 270 lbs. |
| 3/64 inch (1.2mm) | 4/5x4/5 inch (20x20mm) | 270 lbs. |
